Essential details

Daily Capacity: 1T/24 H

Refrigerant: R22/R404A/R507A

Water Inlet Temperature: 25℃

Dry Bulb Temperature: 35℃

Installed Power: 6kw

Power Supply: 50/60Hz,220V/380V/440V, 3P

Operating Weight: 960kg

Dimension(L*W*H): 1800*1200*2000mm

Condenser: Air cooling

Features

1. The evaporator adopts special aluminum alloy plate which is more durable and meets food hygiene requirements.

2. Ice thawing and ice doffing automatic, reducing labor expenses and saving time and effort.

3. The ice is doffed by batch and the whole ice-doffing process only takes 25 minutes.

4. The whole batch of ice blocks can be moved by forklift, quick and convenient.

5. Focusun block ice machines can be optionally equipped with an automatic ice transfer device. The ice moving shelf keeps horizontal with the bottom of ice holding plate. Ice block will be put outside the machine automatically, making transport more convenient.

Principle of ice making

Water will be added automatically to ice cans and directly exchange heat with refrigerant. After a certain ice-making time, the water in the ice tank all becomes ice when the refrigeration system will change into ice doffing mode automatically. It doffs ice with fluorine gas and the ice blocks will fall down in 25 minutes.

Advantage of the block ice

Large blocks of ice are very convenient in terms of storage, handling and transportation. This convenience is important for small-scale fisheries and in relatively remote areas. In addition, block ice is less likely to melt and has the longest shelf life compared to other ice types under the same environmental working conditions.

Supply Ability

Minimum order quantity: 1 unit

Price negotiable

Payment method: T/T, L/C, Western Union, Alibaba

Supply capacity: 60 units/year

Delivery deadline: 30-60 days to ship

Conventional packaging

1. Standard wooden case

2. Machine comes into use, customer only needs prepare power for the machine

3. All required components for installing the machine will be provided

4. Can be shipped in 20 feed or 40 feed containers

About Focusun

FOCUSUN is a pioneer in the fields of ice making and vacuum pre-cooling. We specialized in designing and manufacturing all kinds of high quality ice machines and cooling systems. With the technology and experience accumulated over the years, we use advanced technology of refrigeration and mechanical transmisson to provide quality service to more than 11,000 professional clients in 56 countries around the world.
