Essential details

Daily Capacity: 10T/24 H

Refrigerant: R22/R404A/R507A

Water Inlet Temperature: 25℃

Dry Bulb Temperature: 35℃

Installed Power: 33.9kw

Power Supply: 50/60Hz,220V/380V/440V, 3P

Operating Weight: 7400kg

Dimension(L*W*H): 12192*2438*2895mm

Condenser: Air cooling/Water cooling/Evaporative cooling

Container Dimensions: 40 feet

Features

1. Simple installation and convenient transportation, no need to build a room for the container and machine.

2. Self-contained condensing unit is pre-piped and wired, simple to operate.

3. New ISO 20’/40′ container equipped with lighting and drainage system.

4. Operation expenses and cost-saving, simple maintenance, long service time.

5. Corrugated aluminum floors, skid and wear resistant.

Principle of ice making

1. Put the ice buckets filled with water in the brine tank.

2. Through heat exchange, the water in the ice bucket is frozen into ice.

3. The crane will hoist a row of buckets down into the ice thawing tank full of running warm water.

4. Ice surface thaws and gets separated from the ice bucket.

Supply Ability

Minimum order quantity: 1 unit

Price negotiable

Payment method: T/T, L/C, Western Union, Alibaba

Supply capacity: 60 units/year

Delivery deadline: 30-60 days to ship

Conventional packaging

1. Standard wooden case

2. Machine comes into use, customer only needs prepare power for the machine

3. All required components for installing the machine will be provided

4. Can be shipped in 20 feed or 40 feed containers

About Focusun

FOCUSUN is a pioneer in the fields of ice making and vacuum pre-cooling. We specialized in designing and manufacturing all kinds of high quality ice machines and cooling systems. With the technology and experience accumulated over the years, we use advanced technology of refrigeration and mechanical transmisson to provide quality service to more than 11,000 professional clients in 56 countries around the world.
