1. Ice skate, water sprinkling pan, principle axis and low water pan are driven by decelerator and run slowly counterclockwise.

2. The water flows into the water distributive pan from the water inlet of evaporator, and then sprinkles over on the ice freezing surface evenly through water sprinkler, becoming a water film.

3. The water film has a heat exchange with the refrigerant in the refrigerant runner and its temperature quickly decreases till forming of a layer of thin ice on ice freezing surface.

4. Under the extrusion of ice skate, the thin ice layer turns into ice flake and then falls into ice storage bin from the ice outlet.

5. The partial unfrozen water then returns to the cold water tank through water receiving plate from water return outlet.

Advantage of the flake ice

1. Irregular ice flakes with size about 40*40mm and thickness around 1.5-2.5mm.

2. The thin ice can be directly used for stirring and mixing refrigerated materials.

3. No acute edges and corners so it will not damage the surface of the cooled object.

4. Large contact area and fast cooling speed.

5. Easy to crush and mold.

Features

1. Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant.

2. Stainless steel materials, advanced processing equipment and heat treatment processing ensure the best heat transfer efficiency.

3. The design of large water receiving plate can prevent water leaking at the bottom of evaporator.

4. Photoelectric switch is directly installed at the bottom of the evaporator to realize automatic control of full ice.

5. Direct liquid feeding and dry evaporation, simple& safe to control.

Supply Ability

Minimum order quantity: 1 unit

Price negotiable

Payment method: T/T, L/C, Western Union, Alibaba

Supply capacity: 60 units/year

Delivery deadline: 30-60 days to ship

Conventional packaging

1. Standard wooden case

2. Machine comes into use, customer only needs prepare power for the machine

3. All required components for installing the machine will be provided

4. Can be shipped in 20 feed or 40 feed containers

About Focusun

FOCUSUN is a pioneer in the fields of ice making and vacuum pre-cooling. We specialized in designing and manufacturing all kinds of high quality ice machines and cooling systems. With the technology and experience accumulated over the years, we use advanced technology of refrigeration and mechanical transmisson to provide quality service to more than 11,000 professional clients in 56 countries around the world.
